PP Plastic Pump
PP Plastic Pump
Our PP Plastic Pump under the AODD (Air Operated Double Diaphragm) category is designed for efficient and reliable fluid transfer across various industrial applications. Made from high-quality polypropylene, it offers excellent resistance to corrosive chemicals, making it ideal for handling acids, alkalis, and aggressive fluids.
Built for durability and low maintenance, this pump ensures smooth, leak-free operation with consistent performance. Its air-operated mechanism eliminates the need for electricity, making it a safe and cost-effective solution for demanding environments.
| Technical Parameter | |
|---|---|
| Max. Suction Lift | Dry 2.5m |
| Suction height changes with the different combinations of ball, seat and the diaphragm materials | Wet 4.4m |
| Max. Particle Diamete | 1.5mm |
| Suction and Discharge Size | 1/4in /Npt |
| Air Inlet Size | 1/4in |
| Max. Flow Rate | 18 l/min |
| Max. Head | 70m |
| Max. Air Inlet Pressure | 7 bar |
| Max. Air Consumption | 9.0 scfm（0.252m³/min） |
| Main Body Material | PP、Acetal、PVDF |
| Technical Parameter | |
|---|---|
| Max. Suction Lift | Dry 4m |
| Suction height changes with the different combinations of ball, seat and the diaphragm materials | Wet 7.6m |
| Max. Particle Diamete | 2.5mm |
| Suction and Discharge Size | 1/2 3/4in /Npt |
| Air Inlet Size | 1/4in |
| Max. Flow Rate | 57 l/min |
| Max. Head | 84m |
| Max. Air Inlet Pressure | 8.4 bar |
| Max. Air Consumption | 28scfm（0.672m³/min） |
| Main Body Material | PP、Acetal、PVDF |
| Technical Parameter | |
|---|---|
| Max. Suction Lift | Dry 4m |
| Suction height changes with the different combinations of ball, seat and the diaphragm materials | Wet 7.6m |
| Max. Particle Diamete | 2.5mm |
| Suction and Discharge Size | 1/2 3/4in /Npt |
| Air Inlet Size | 1/4in |
| Max. Flow Rate | 57I/min |
| Max. Head | 84m |
| Max. Air Inlet Pressure | 8.4 bar |
| Max. Air Consumption | 28scfm（0.672m³/min） |
| Main Body Material | PP、Acetal、PVDF |
| Technical Parameter | |
|---|---|
| Max. Suction Lift | Dry 4m |
| Suction height changes with the different combinations of ball, seat and the diaphragm materials | Wet 8m |
| Max. Particle Diamete | 4mm |
| Suction and Discharge Size | 1in /Npt/F |
| Air Inlet Size | 1/4in |
| Max. Flow Rate | 157 l/min |
| Max. Head | 84m |
| Max. Air Inlet Pressure | 8.4 bar |
| Max. Air Consumption | 60scfm（1.7m³/min） |
| Main Body Material | PP、Acetal、PVDF |
| Technical Parameter | |
|---|---|
| Max. Suction Lift | Dry 5m |
| Suction height changes with the different combinations of ball, seat and the diaphragm materials | Wet 8m |
| Max. Particle Diamete | 5mm |
| Suction and Discharge Size | 1½in/Npt/F |
| Air Inlet Size | 1/2in |
| Max. Flow Rate | 358 l/min |
| Max. Head | 84m |
| Max. Air Inlet Pressure | 8.4 bar |
| Max. Air Consumption | 125scfm（3.5m³/min） |
| Main Body Material | PP、Acetal、PVDF |
| Technical Parameter | |
|---|---|
| Max. Suction Lift | Dry 5m |
| Suction height changes with the different combinations of ball, seat and the diaphragm materials | Wet 8m |
| Max. Particle Diamete | 6mm |
| Suction and Discharge Size | 2in /Npt/F |
| Air Inlet Size | 1/2in |
| Max. Flow Rate | 587 l/min |
| Max. Head | 84m |
| Max. Air Inlet Pressure | 8.4 bar |
| Max. Air Consumption | 175scfm（4.9m³/min） |
| Main Body Material | PP、Acetal、PVDF |
| Advantage |
|---|
| Explosion-proof, zero leak, simple operation |
| Idling capability，Self suction， No complex control |
| Can transmit the adhesive liquid and large particles |
| low shearing，Not easy to destroy material structure |
| Diversity of material，no rotating parts，applicable to various erosive situations |
| By changing the air supply to adjust the flow delivery |
×
